Lithium Polymer Cells
5s Lipo Battery 180Ah
5SLi-ion polymerOEM / ODM
This 22.2V 180Ah Li-ion polymer battery pack (5S) is built by Jetray Battery for drones and RC models, wearables and portable electronics, medical and handheld devices. Cells, BMS settings, connector, wiring and housing can all be built to your specification.
Specifications
Technical data
Standard model values. Every parameter below can be adjusted for your project.
Configuration5S
Nominal Voltage22.2V
Capacity180Ah
Battery ModelJT-CATL6S1P
ChemistryLi-ion polymer
Cycle Life3000 times
Dimensions153*440*120mm
Weight15KG / 17.6KG
Operating Temperature0~55Centigrade
Temperature window °C
Operating0 to 55 °C
03060
Need different specs?
Send your voltage, capacity, current and size limits. We build packs to your drawing.
Runtime estimator
Size the pack to your load
Enter your load and the number of packs in parallel to estimate current, C-rate and runtime.
W
System: 22.2 V · 180 Ah · 3996 Wh
–Current (A)
–C-rate
–Est. runtime
0.5C1C
Ideal estimate at nominal voltage and capacity; reference rate 1C (assumed). Real results vary with temperature, cell age and cut-off settings. Packs in parallel must be matched — ask our engineers first.
Applications
Where it is used
Drones and RC models
Wearables and portable electronics
Medical and handheld devices
Robotics and smart devices
Customization & BMS
Built around your equipment
Voltage, capacity, size, BMS and communication can all be changed for OEM / ODM projects. Start from this model or from your own drawing.
FAQ & safety
Common questions
We offer Li-ion (NCM / NCA), LiFePO4 and LTO cells, chosen to match your project needs.
Yes. We provide structural design so the pack fits your housing, connector and mounting points.
Overcharge, over-discharge, overcurrent, short-circuit and temperature protection, SOC / SOH display and communication protocols such as CAN and RS485.
Yes. Charging rates from 0.5C to 2C are possible, depending on the cell specification.
Typically 12–36 months, depending on the project agreement.
Keep them at 50–60% state of charge in a dry, ventilated place between −10 °C and 35 °C.
Safe handling
Heat and damage
Never heat, disassemble or modify the battery, or dispose of it in a fire. Do not pierce, hit, step on or drop it.
If fluid leaks
Do not touch it with bare hands. Rinse eyes, mouth or skin with clean water, see a doctor if needed and contact Jetray after-sales.
Keep it dry
Do not get the battery wet.
Storage conditions
Do not use or store the battery in direct sunlight, high heat or humidity, a hot car, or near heat sources.
