12V 6Ah LiFePO4 Battery
Lead-Acid Replacement Battery Packs

12V 6Ah LiFePO4 Battery

4S1PLiFePO4Lifepo4 Battery PackOEM / ODM

This 12V 6Ah LiFePO4 battery from Jetray Battery comes with a built-in BMS and is designed for drop-in replacement of 12V lead-acid / AGM batteries, RVs, campers and marine use, solar lighting and off-grid power. Capacity, communication protocol, terminals and enclosure can be configured for your system.

  • Nominal voltage12V
  • Capacity6Ah
  • Energy72Wh
  • Max discharge6A
  • Fully customizableVoltage, capacity, BMS, housing
  • Documents readyDatasheet, MSDS, UN38.3
  • 24-hour replyDirect from our engineers
Specifications

Technical data

Standard model values. Every parameter below can be adjusted for your project.

Configuration4S1P
Nominal Voltage12V
Capacity6Ah
Battery ModelFP-LP-Black1
ChemistryLiFePO4
CellLifepo4 Battery Pack
Shipment Voltage12.8V
Discharge Cut-off Voltage10V
Max Charge Current3A
Max Continuous Discharge Current6A
Dimensions15165100mm (LWH)
Weight1KG
Max Capacity6Ah
Discharge Cut-off Current≤1A
Enclosure RatingIP65
Material Of ShellABS
Need different specs?

Send your voltage, capacity, current and size limits. We build packs to your drawing.

Applications

Where it is used

Drop-in replacement of 12V lead-acid / AGM batteries
RVs, campers and marine use
Solar lighting and off-grid power
UPS and emergency backup
Customization & BMS

Built around your equipment

Voltage, capacity, size, BMS and communication can all be changed for OEM / ODM projects. Start from this model or from your own drawing.

FAQ & safety

Common questions

We offer Li-ion (NCM / NCA), LiFePO4 and LTO cells, chosen to match your project needs.

Yes. We provide structural design so the pack fits your housing, connector and mounting points.

Overcharge, over-discharge, overcurrent, short-circuit and temperature protection, SOC / SOH display and communication protocols such as CAN and RS485.

Yes. Charging rates from 0.5C to 2C are possible, depending on the cell specification.

Typically 12–36 months, depending on the project agreement.

Keep them at 50–60% state of charge in a dry, ventilated place between −10 °C and 35 °C.

Safe handling

Heat and damage

Never heat, disassemble or modify the battery, or dispose of it in a fire. Do not pierce, hit, step on or drop it.

If fluid leaks

Do not touch it with bare hands. Rinse eyes, mouth or skin with clean water, see a doctor if needed and contact Jetray after-sales.

Keep it dry

Do not get the battery wet.

Storage conditions

Do not use or store the battery in direct sunlight, high heat or humidity, a hot car, or near heat sources.
