24V Lithium Battery Pack
We manufacture 24V Lithium Battery Packs using advanced cell sorting and assembly technology.
As a leading 24V lithium battery pack manufacturer, we maintain strict quality control throughout the production process and support small-batch customization for pilot projects or special applications.
We also keep a wide range of standard models in stock, including 24V 10Ah, 12Ah, 13Ah, 20Ah, and 100Ah, ready for fast delivery.
Whether you need OEM, ODM, or custom-made battery packs, our engineering team can design solutions tailored to your voltage, current, connector, and casing requirements.
-
Type: Lithium-ion Battery Pack
-
Rated Capacity: 100Ah
-
Nominal Voltage: 24V
-
Battery Model: 24V 12Ah
-
Typical Capacity: 12Ah (0.2C Standard Discharge)
-
Nominal Voltage: 24V
-
Battery Model: 24V 13Ah
-
Typical Capacity: 13Ah (0.2C Standard Discharge)
-
Nominal Voltage: 25.2V
-
Model: 24V 20Ah
-
Nominal Voltage: 25.9V
-
Typical Capacity: 20Ah (0.2C Standard Discharge)
Not Sure Where to Start?
We can help you find the right solution that suits your business needs, whether you are looking for product information, customized content, or service processes, we can provide assistance!
What Is a 24V Lithium Battery Pack?
A 24V lithium battery pack is a rechargeable power source made by connecting lithium cells in series. It usually runs between 19.6V and 29.4V depending on charge level. These packs are popular for mobility devices, solar systems, and industrial tools because they offer more power than 12V systems but stay safe and compact.
Why Choose 24V Instead of 12V?
A 24V system needs only half the current of a 12V system to deliver the same power.
That means less heat, thinner cables, and better efficiency.
It’s ideal for medium-power machines that need longer working hours, such as e-bikes, trolleys, or cleaning robots.
12V systems fit small gadgets.
48V or higher is for heavy machinery.
24V sits in the sweet middle—safe, strong, and easy to manage.
Key Features
Stable output voltage around 25.2V
Typical capacity from 10Ah to 100Ah
Lightweight and compact design
Built-in BMS protection (over-charge, over-discharge, short circuit)
Rechargeable more than 500–2000 cycles depending on cell type
Main Applications
1. Electric Vehicles & Mobility
Used in e-bikes, scooters, golf carts, and small forklifts.
It provides smooth power with good acceleration and long life.
2. Marine and Boat Systems
24V packs power trolling motors and navigation systems.
They deliver strong current while resisting vibration and salt exposure.
3. Solar Energy Storage
Often paired with solar charge controllers and inverters.
A 24V battery bank balances cost, efficiency, and energy density for off-grid systems.
4. Industrial and Cleaning Equipment
Robotic cleaners, portable tools, and small AGVs use 24V systems for steady output and long runtime.
5. Backup and Communication Systems
In UPS and telecom setups, 24V batteries act as reliable standby power when the grid fails.
How to Choose the Right 24V Pack
When selecting a pack, check these points:
Capacity (Ah): higher means longer use time.
Max discharge current: must match your motor or inverter.
Cycle life: good lithium cells last 1000+ cycles.
Size and weight: choose what fits your system.
Certifications: CE, UN38.3, MSDS, etc. for safe transport and use.
Safety Tips
Always use a matching 29.4V charger for 24V packs.
Avoid deep discharge below 17–18V.
Keep batteries dry and ventilated.
If storing long-term, keep charge around 50–60%.
Don’t mix different packs or brands in one system.
24V vs 48V Battery
| Model | Size | Capacity Range | Typical Applications |
|---|---|---|---|
| 18650 | 18 × 65 mm | 1800–3500 mAh | Laptops, power banks, e-bikes |
| 14500 | 14 × 50 mm | 600–1000 mAh | Flashlights, toys |
| AA lithium primary (Li-SOCl₂) | AA size | 2000–2600 mAh | Industrial sensors, meters |
| Button cells (CR123A, etc.) | Coin-sized | 150–1000 mAh | Cameras, alarms, security devices |
Future Trends
Modern 24V lithium packs now use LiFePO₄ and NMC cells.
They are lighter, last longer, and charge faster than old lead-acid batteries.
Some include smart BMS for Bluetooth monitoring and automatic balancing.
